Discrete design and size is restrained
Source switched built-in high efficiency: consumption reduced
Manufacturing completely automated and subjected to rigorous quality controls
Constrol manual gain, protected by a hinged cover
Heavy duty screw in wall
Connectors IEC
Entries | 1 (CEI) |
||
Frequency range | MHz | 47...790 | |
Gain | G | dB | 25 |
Margin regulation gain |
marg | 15 | |
Level of output | DIN 45004B Vout | dBµV | >112 |
IMD3 (2tones, -35dB) Vout | 119 | ||
Noise figure | N. F. | dB | 6 |
Power/current max. entries |
ON | Vdc/ mA |
- |
OFF | - | ||
Voltage/frequency network | V~/Hz | 196...253/50...60 | |
Consumption total AC | W/mA | 2,3/23 | |
Index of protection | IP | 20 | |
Temperature range of operation | ºC | -5 ... +45 |
