Ceiling motion detector, 1-channel flush mounting with 16A inverted relay, LED/UV lamp

DINUY DM TEC IV8
Out of stock
€141.38
VAT included

• Motion detector, with PIR technology, for recessed ceiling mounting.
• It has 1 output channel with a 16A relay, free of voltage, and normally closed contact.
• Logic of Reverse operation: turns off the lighting when movement is detected.
• A second timing allows the lighting to be activated once movement is no longer detected and the set delay time has elapsed.
• Maximum coverage of 360º and Ø7m, at 2.5m height.
• Zero crossing switching, which allows the protection of its relay and high power switching.
• Valid for all types of lamps, including LED and UV.
• Example of application: control of germicidal lamps for the disinfection of rooms or rooms.

Description

Product reference DM TEC IV8
Supply Voltage (V) 230V
Frequency (Hz) 50
Own Consumption <1W
LED Lamps (W) 400W
Incandescent and Halogen 230V (W) 3000W
Halogen 12V with electronic transformer (W) 3000W
Halogen with ferromagnetic transformer (W) 2400W
Detection Angle (º) 360
Mounting height (m) 2.5
Detection diameter (m) 7
Detection length (m) 0
Minimum time delay (seconds) T1 (detection delay): 1min/T2 ( activation delay): 5min ~ 90min or canceled
Recessed ceiling mounting
Fluorescent lamps (VA) 1,300W
Contactor supported Yes
Zero crossing Yes
Temperature Operating Temperature (ºC) (min) -10
Operating Temperature (ºC) (max) 45
Environmental Protection IP40

Product Details

EAN
8422447017403
Manufacturer
Dinuy
Reference
DINUY DM TEC IV8
Certification
CE
